LJ Audio 8W3-V2-D2 Subwoofer
Since their introduction in 1998, JL Audio W3 subwoofers have earned a reputation for outstanding performance and reliability. The introduction of this next generation, the W3v2 models, signals the arrival of some significant upgrades to these already impressive drivers:
In addition to JL Audio’s patented VRC™ technology, the 10W3v2 and 12W3v2 also incorporate our patented Elevated Frame cooling technology for enhanced thermal dissipation and 20% more power handling than the original 10W3 and 12W3. Cosmetic upgrades include a new powder-coated silver frame finish, a new dished cone/dust-cap design and a rubber mounting flange gasket that accepts grille mesh inserts directly (these grille inserts are sold separately).
The W3v2 subwoofer drivers deliver exceptional tonal balance and impressive output in compact enclosures and are ideal for moderate to high power applications.
The 8W3v2 is a remarkable 8-inch subwoofer with very long excursion capability, designed to extract maximum performance from moderate power levels. This speaker works extremely well in very small sealed and ported enclosures while its dual voice coil design gives the user a high degree of application flexibility.
Specifications
Nominal Diameter: 8 inches (200 mm)
Continuous Power Handling: 125 Watts
Voice Coil: 1.43" diameter, 4-layer, Kapton former
Available Configurations: Dual 2 ohm, Dual 4 ohm or Dual 6 ohm
Xmax (one-way, linear): 0.38" (9.5 mm)
Sealed Enclosure Range: 0.30-0.50 cu.ft. (8.5-14.0 liters)
Ported Enclosure Range: 0.60-0.90 cu.ft. (17.0-25.5 liters)
VRC™ Technology: YES
Elevated Frame Technology: No
